Robotic Arm Joint Housing
A hollow joint housing for collaborative robot arms, gravity cast in A356 and T6 heat-treated, then machined on 5-axis centres so the bearing seats and gearbox flange need no secondary work.
Product Overview
A hollow joint housing for collaborative robot arms, gravity cast in A356 and T6 heat-treated, then machined on 5-axis centres so the bearing seats and gearbox flange need no secondary work.
What Makes This Part Reliable
- T6 heat treatment lifts yield strength roughly 40% over the as-cast condition.
- 5-axis machining keeps the bearing bores and flange faces true to each other.
- Hollow rib design cuts rotating mass without losing torsional stiffness.
Typical Applications
Specifications
| Part Code | LDW09 |
|---|---|
| Material / Alloy | A356-T6 |
| Manufacturing Process | Gravity Casting + 5-Axis CNC |
| Application Industry | Robotics |
| Typical Weight | 1.5 – 4 kg |
| Dimensional Tolerance | ±0.05 mm |
| Surface Treatment | Anodizing · Shot blasting · Painting |
| Dimensional Standard | ISO 8062 CT7–CT9 |
| MOQ | 100 pcs |
| Lead Time | Sample 4–7 days · Mass production 15–30 days |
| Inspection | CMM, spectrometer, X-ray, hardness, metallographic |
| Part Category | Gravity Casting |
| Drawing Format | STEP / IGES / X_T / DWG / PDF — 2D & 3D both accepted |
Values shown are typical for this part family. Send your drawing and we will confirm the exact alloy, tolerance and price for your application.
Process Flow
- RFQ & DFMEngineers review your drawing, wall thickness, draft and tolerances, then recommend the process.
- QuotationWritten quote within 24 hours — tooling, unit price and lead time.
- ToolingIn-house mold or pattern, checked against a mold-flow simulation before cutting.
- T1 SampleFirst article shipped with a CMM report for your approval.
- Mass ProductionStable process parameters, in-line inspection and full lot traceability.
- Machining & SurfaceCNC finishing, then shot blasting or the treatment you specify.
- Final InspectionCMM, spectrometer, X-ray, hardness and metallographic analysis.
- Packaging & ShipmentExport carton or crate with desiccant; DDP available on request.
